Features
- Low weight, good balance, easy to manoeuvre
- Extended reach with long cutter bar
- Long life gear components
- Exhaust fumes diverted away from the user
- Auto return stop switch for easy starting
- Sharp, robust cutting knife for best capacity
 |
Long life gear components
The gear components have been developed for long life under tough conditions.
|
Long cutter bar
Long cutter bar for extended reach |
|
 |
Low weight
The hedge trimmer’s low weight and balanced centre of gravity make |
 |
Engine position
The engine position also helps divert exhaust fumes away from the user. |
Specifications
| Capacity | |
| Cutting speed | 4339 cut/min |
| Recommended maximum twig diameter | 24 mm |
| Dimensions | |
| Full length, including cutting equipment | 192 cm |
| Length, transportation mode – metric | 192 cm |
| Weight | 6.1 kg |
| Engine | |
| Cylinder displacement | 25.4 cm³ |
| Electrode gap | 0.65 mm |
| Fuel consumption | 395 g/kWh |
| Fuel consumption | 395 kg/h |
| Fuel tank volume | 0.51 l |
| Idling speed | 3000 rpm |
| Maximum power speed | 8500 rpm |
| Power output | 0.9 kW |
| Spark plug | NGK BPM8Y |
| Equipment | |
| Knife adjustment range, up/down Down | 0 ° |
| Knife adjustment range, up/down Up | 0 ° |
| Knife Length | 65 cm |
| Teeth opening | 30 mm |
| Sound and Noise | |
| Sound power level, guaranteed (LWA) | 105 dB(A) |
| Sound power level, measured | 106 dB(A) |
| Sound pressure level at operators ear | 92 dB(A) |
| Transmission | |
| Gear ratio | 1 |
| Gear ratio | 5.53 |
| Vibration | |
| Equivalent vibration level (ahv, eq) front handle | 3.9 m/s² |
| Equivalent vibration level (ahv, eq) rear handle | 2.9 m/s² |
| Engine Family EPA | EHQZS.0254GB |
| Engine Family CARB | EHQZS.0254GB |
| Exhaust emissions (CO average) | 354.3 g/kWh |
| Exhaust emissions (CO FEL) | 536 g/kWh |
| Exhaust emissions (CO average) | 1052 g/kWh |
| Exhaust emissions (HC+NOx FEL) | 50 g/kWh |
| Exhaust emissions (HC average) | 37.7 g/kWh |
| Exhaust emissions (NOx average) | 0.1 g/kWh |
| Exhaust emissions (PM FEL) | 2 g/kWh |
| Useful life category | 300 hrs |
| Basic model | e13*97/68SH2G3*2012/46*0765*00 |
| Emission durability period (EDP) | GZ26S16 |
| Exhaust emissions (CO average) | 300 hrs |
| Exhaust emissions (CO FEL) | 354.3 g/kWh |
| Exhaust emissions (CO average) | 805 g/kWh |
| Exhaust emissions (HC+NOx FEL) | 1052 g/kWh |
| Exhaust emissions (HC average) | 50 g/kWh |
| Exhaust emissions (NOx average) | 37.7 g/kWh |
| Exhaust emissions (PM FEL) | 0.1 g/kWh |
| Useful life category | 300 hrs |
| Engine Family EU | GZ26S |
| EU type approval | Stage 2 |
| Exhaust emissions (CO average) | 87.57 g/kWh |
| Exhaust emissions (HC+NOx FEL) | 19.38 g/kWh |
| Exhaust emissions (NOx average) | 0.56 g/kWh |
