Features
- ClearCut™ fabricated cutting deck
- Maintenance-free hydraulic transmission
- Rugged frame and casters ensure durability
- Convenient deck lift
- Ergonomic control panel
- Removable foot plate
- Anti-slip foot area
- Bumper
- Refinement
- Automatic park brake system
- Endurance Commercial Engine
- Rear engine guard
 |
Rugged frame and casters
The robust frame and casters ensure durability and reduced chassis flex. |
 |
Maintenance-Free Transmission
Worry free performance with maintenance free, integrated zero- turn transmissions. |
 |
ClearCut™ fabricated cutting deck
ClearCut™ deck technology features deep deck design, air flow control baffles, high performance blades and top discharge for superior cutting performance whether discharging, bagging or mulching. |
 |
Convenient deck lift
The deck lift system is spring assisted for ease of use and conveniently located within easy reach of the operator. |
Specifications
| Battery | |
| Battery capacity | 18 Ah |
| Battery type | Lead / Acid |
| Battery voltage | 12 V |
| Capacity | |
| Blade-tip speed | 93.98 m/s |
| Horsepower | 17.15 kW |
| Power output | 16.4 kW |
| Certifications | |
| Commercial Warranty | No warranty |
| Homeowner Warranty | 3 Years |
| Dimensions | |
| Article gross weight | 329308 g |
| Article net weight | 259908 g |
| Base machine, height | 101.6 cm |
| Base machine, length | 190.5 cm |
| Base machine, width (chute down) | 129.54 cm |
| Base machine, width (chute up) | 110 cm |
| Base machine, width | 122 cm |
| Cutting height steps | 6 |
| Deck thickness | 3.5 mm |
| Seat back height | High |
| Weight | 255.825 kg |
| Wheel/rim size, front Diameter | 5 in |
| Wheel/rim size, rear Diameter | 8 in |
| Engine | |
| Cylinder displacement | 724 см³ |
| Cylinders | 2 |
| Engine cooling | Air |
| Engine name | Endurance Commercial |
| Motor/engine manufacturer | Briggs & Stratton |
| Motor/engine model | Endurance Commercial |
| Equipment | |
| Air filter type | Auto-type Paper |
| Anti-scalp wheels | 1 |
| Armrests | No |
| BioClip® kit | Available as accessory |
| Blade engagement | Electric clutch |
| Blade type | High-Lift blade |
| Blades | 2 pcs |
| Collector | Available as accessory |
| Cup holder | Yes |
| Cutting deck type | ClearCut™ – Fabricated |
| Cutting methods | Collect/Mulch/Side discharge |
| Deck lifting system | Manual, hand operated |
| Deck Wash Port | yes |
| Drive method | Lever-operated |
| Drive system | Rear wheel drive |
| Drive wheels | rear |
| Electric start | yes |
| Headlights | no |
| Hour meter type | Digital with pre-programmed service intervals |
| Nose roller | Yes |
| Seat spring | Yes |
| Seat type | 15″ high back |
| Lubricants | |
| Engine lubrication type | Full pressure with oil filter |
| Fuel consumption | 6.89 l |
| Fuel tank location | Side (single) |
| Fuel tank volume (with reserve) | 13.25 l |
| Oil capacity | 2.1 l |
| Oil filter | Yes |
| Power/fuel type | Gasoline |
| Materials | |
| Cutting deck material | Steel |
| Powder-coated cutting deck | Yes |
| Seat material | Vinyl |
| Spindle/mandrel type | Cast iron |
| Packaging | |
| Packaging gross weight | 69.16 kg |
| Packaging height | 876 mm |
| Packaging length | 1981 mm |
| Packaging volume | 2791.08 dm³ |
| Packaging weight | 315.25 kg |
| Packaging width | 1549 mm |
| Quantity in Master pack | 1 |
| Sound and Noise | |
| Sound level | 100 dB(A) |
| Sound power level, guaranteed (LWA) | 100 dB(A) |
| Sound power level, measured | 100 dB(A) |
| Sound pressure level at operators ear | 86 dB(A) |
| Vibration | |
| Vibration level seat | 0.29 m/s² |
| Vibration level steering wheel | 1.9 m/s² |
