Features
- Constant-flow water valve
- Ergonomically designed rear handle
- Increased productivity
- Zero COâ‚‚ emissions during use
- Easy serviceability
- Simple blade change
- “Pulling” rotation
- High durability and low noise levels
- Overload protection
- Perfect for indoor use
- Elgardâ„¢
- Electronic Softstartâ„¢
- Adjustment to openings
- Blocks, curbstones and pavers
- Cast concrete
- Deep cutting
- Floors and walls
- Grooves
- Pipes
 |
Constant-flow water valve
The integrated regulator controls the water volume, ensuring a constant flow to the blade. It also ensures the amount of water is sufficient to bind the dust without creating an excess of water.
|
 |
Easy serviceability
The one-piece inspection lid and Torx screws make it easy to assemble and service. |
 |
Simple blade change
Quick acting locks for the spindle and a large outlet in the blade guard simplifies blade replacement. |
 |
“Pulling” rotation
The blade on all our electric cutters rotates forward, cutting into the material efficiently, minimising the risk of sticking and kickbacks. |
Specifications
| Engine | |
| Rated input power | 2.7 kW |
| Frequency | 50-60 Hz |
| Voltage | 220-240 V |
| Phases | 1 & 3 ph |
| Power source | Corded |
| Cutting Equipment | |
| Cutting depth (max) | 125 mm |
| Blade diameter (max) | 350 mm |
| Arbor diameter | 25.4 mm |
| Blade thickness (max) | 5.6 mm |
| Peripheral speed (max) | 100 m/s |
| Coolant | Wet / Dry |
| Dimensions | |
| Weight | 7.6 kg |
| Product size length | 631 mm |
| Product size width | 221 mm |
| Product size height | 313 mm |
| Sound and noise | |
| Sound power level guaranteed (LWA) | 105 dB(A) |
| Sound pressure level at operations ear | 95 dB(A) |
| Vibrations | |
| Vibrations left/front handle | 3.5 m/s² |
| Vibrations right/rear handle | 3.5 m/s² |
