Features
- Less filter cleanings with Air Injection
- Adjustable chain oil pump
- Quick-release air filter
- Intuitive, combined choke/stop control
- Quick and easy chain adjustment
- Magnesium crankcase designed for professional use
 |
Quick-release air filter
Facilitates cleaning and replacement of the air filter. |
 |
Adjustable oil pump
Adjustable oil pump makes it easy to set the chain lubrication according to your needs. |
 |
Air Injection
Centrifugal air cleaning system for reduced wear and longer operating time between filter cleanings. |
 |
Combined choke/stop control
Combined choke/stop control allow for easier starting and reduce the risk of engine flooding. |
Specifications
| Capacity | |
| Chain speed at 133% of maximum engine power speed | 23m/s |
| Chain speed at max power | 17.3m/s |
| Clutch engagement speed(± 120) | 3780rpm |
| Idling speed | 2700 rpm |
| Ignition module air gap | 0.3 mm |
| Maximum power speed | 9000 rpm |
| Power output | 2.4 kW |
| Torque. max. | 2 Nm |
| Torque. max. at rpm | 6600 rpm |
| Certifications | |
| Cert machine dir. 2006/42/EC Deel. No. | 0404/09/2085 |
| Recyclabillity. today | 80% |
| Recyclable of weight of FE. Al and Mg | 45% |
| Dimensions | |
| Article gross weight | 7349g |
| Article net weight | 5800g |
| Bar length (inch) | 18in |
| Bar length | 450mm |
| Weight (excl. battery and cutting equipment) | 5 kg |
| Engine | |
| Carburetor | Zama C3-EL5 l |
| Cylinder bore | 45mm |
| Cylinder displacement | 51.7cm |
| Cylinder stroke | 32.5mm |
| Electrode gap | 0.5mm |
| Ignition module air gap | 0.3mm |
| Max engine/motor RPM | 13000 rpm |
| Spark plug | Champion RCJ7Y. NGK BPMR7 A |
| Equipment | |
| Bar mount type | Small |
| Chain type | H25 |
| Chainsaw sub-group | Full time professional use chainsaws |
| Gauge | 1.5mm |
| Handle type | Standard |
| Pitch | .325″ |
| Source system | PAID |
| Sprocket type | Rim 7 |
| Lubricants | |
| Fuel consumption | 531 g/kWh |
| Fuel consumption | 1.26 kg/h |
| Fuel tank volume | 0.51 |
| Fuel type, min (Europe) | RON min 91 or alkylate |
| Lubricant type | Husqvarna 2 stroke or equiv at 50:1 |
| Oil pump capacity Max | 12 ml/min |
| Oil pump capacity Min | 5 ml/min |
| Oil pump type | Automatic |
| Oil tank volume | 0.281 |
| Power /luel type | Gasoline |
| Emission Data EPA | |
| Exhaust emissions (CO average) | 345 g/kWh |
| Exhaust emissions (CO average) | 888 g/kWh |
| Exhaust emissions (HC average) | 126 g/kWh |
| Exhaust emissions (NOX average) | 2.5 g/kWh |
| Sound and Noise | |
| Sound level | 102 dB(A) |
| Sound power level.guaranteed (LWA) | 115 dB(A) |
| Sound power level. measured | 114 dB(A) |
| Sound pressure level at operators ear | 102 dB(A) |
| Vibrations | |
| Daily Vibration (Aeqv) | 3.2mis’ |
| Daily Vibration Exposure (AB) | 2.18mis’ |
| Daily Vibration Time (Time factor) | 3.7h |
| Equivalent vibration level (ahv. eq) front handle | 3.1mis’ |
| Equivalent vibration level (ahv. eq) rear handle | 3.2mis’ |
| Vibrations left/Iron! handle | 3.1 m/s2 |
| Vibrations right/rear handle | 3.2 mis’ |
