Specifications
Do you need further details to make the right decision? Learn more in the specifications section below.
Engine |
Cylinder displacement |
40 cm³ / 2.4 cu.inch |
Cylinder bore |
40.5 mm/ 1.59 inch |
Cylinder stroke |
31 mm / 1.22 inch |
Power output |
1.52 kW |
Maximum power speed |
9000 rpm |
Fuel tank volume |
0.25 lit / 8.45 fl oz |
Fuel consumption |
454 g/kWh |
Ignition module air gap |
0.4 mm / 0.02″ |
Idling speed |
3000 rpm |
Spark plug |
TORCH CMR7H |
Electrode gap |
0.6mm / 0.02″ |
Torque, max. |
1.73 Nm / 8000 rpm |
Lubricants |
Oil tank volume |
0.15 lit / 0.32 US pint |
Oil pump type |
Automatic |
Vibration and Noise Data |
Equivalent vibration level (ahv,eq) front / rear handle |
6.7 / 5.8 m/s2 |
Sound pressure level at operators ear |
99 dB(A) |
Sound power level, guaranteed (LWA) |
111 dB(A) |
Cutting Equipment |
Chain pitch |
3/8″ |
Chain speed at 133% of maximum engine power speed |
9.53 m/s / 31.27 fts |
Chain gauge |
0.05″ |
Sprocket type |
Spur 6 |
Bar mount |
Small |
Bar mount |
Large |
Dimensions |
Weight (excl. cutting equipment) |
4.4 kg / 9.7 lbs |
