Features
- Commercial Grade Power
- Operator Convenience
- Patented Suspension System
- Exceptional Performance
- Integrated Transmissions
- Easy Access to Top Deck
- Bumper Protection
- Mower Spindles
- Adjustable Cut Height
 |
Efficient diesel power
Ergonomic riding mower control panel features cup-holder and fuel gauge. |
 |
Patented suspension system
Consists of adjustable rear coil-over-shocks (shown) and front independent adjustable coil-over-shocks. |
 |
Foot-operated deck lift
With adjustable pedal, can change cut height in 1/4″ increments from 1.75″ – 5″. |
 |
Accessibility
Quick removal of the floor pan provides convenient access to the top of the deck for easy cleaning and service. |
Specifications
| Engine | |
| Engine Model | Yanmar™ diesel |
| Displacement | 904 cc |
| Fuel Type | Diesel |
| Fuel Tank Capacity | 11 gal |
| Cylinders | 3 |
| Mowing Decks | |
| Construction | iCD™ Cutting System |
| Cutting Width | 61 inches |
| Cutting Height | 1.75 – 5 inches |
| Speed | |
| Forward | 0 – 10 mph |
| Reverse | 0 – 6 mph |
| Dimensions (Mower & Deck) | |
| Overall width | 76.75 inches |
| Overall length | 86.25 inches |
| Weight | 1,606 lbs |
