Features
- Large wire magazine
- Smooth cutting
- Larger jobs
- Flexible setup
- Tightened wire in the magazine
- Thick walls
- Easy transportation
- Easy to control wire tension
- Confined spaces
 |
Large wire magazine
Although the wire saw is compact, it has a large magazine capacity, enabling larger cuts without cutting the wire.
|
 |
Practical collapsible handles and foldable guard allow easy transportation of the unit. The saw can also be dismantled into sections, which further increases mobility. |
 |
Smooth cutting
The pulleys follow the direction of the wire automatically thanks to the ball bearing turning mechanism. |
 |
Tightened wire in the magazine
The drive wheel is located on the output side of the machine so even when the feeding power is low slack in the wire never occurs in the magazine. |
Specifications
| Engine | |
| Motor for wire drive | Hydraulic multiple gear |
| Output power with PP 455 | 20 kW |
| Spindle starting torque | 190 Nm |
| Power source | Hydraulic |
| Cutting Equipment | |
| Wire speed gear 1 (max) | 20 m/s |
| Wire speed gear 2 (max) | 25 m/s |
| Hydraulics | |
| Hydraulic oil flow | 65 l/min |
| Hydraulic pressure (max) | 230 bar |
| Dimensions | |
| Weight | 150 kg |
| Sound and Noise | |
| Sound power level guaranteed (LWA) | 95 dB(A) |
| Sound power level measured | 94 dB(A) |
| Sound pressure level at operators ear | 83 dB(A) |
| Other | |
| Direction of rotation | One direction |
| Wire configuration in drive unit (min) | 3.4 m |
| Net wire storage capacity | 16 m |
