Features
- Auto return stop switch for easy starting
- Intuitive controls
- Telescopic tube for quick cutting height adjustment
- Magnesium clutch housing ensures long service life
- Rear impact guard
- Adjustable, automatic chain lubrication
 |
Telescopic tube
The tube has a telescopic function for quick cutting height adjustment |
 |
Intuitive controls
The choke and purge are easy to reach and understand. |
 |
Auto return stop switch
Stop switch automatically resets to the ON position for trouble-free starting. |
 |
Magnesium clutch housing
Robust magnesium clutch housing for tough professional use, ensuring a long service life. |
Specifications
| Dimensions | |
| Length, extended, including cutting equipment | 402 cm |
| Weight (excl. cutting equipment) | 7 kg |
| Engine | |
| Cylinder displacement | 1.55 cu.inch |
| Cylinder displacement | 25.4 cm³ |
| Fuel consumption | 395 g/kWh |
| Fuel tank volume | 17.25 fl oz |
| Fuel tank volume | 0.51 l |
| Idling speed | 3000 rpm |
| Maximum power speed | 8500 rpm |
| Power output | 1.34 hp |
| Power output | 1 kW |
| Lubricant | |
| Oil tank volume | 0.3 US pint |
| Oil tank volume | 0.14 l |
| Sound and Noise | |
| Sound power level, guaranteed (LWA) | 107 dB(A) |
| Sound pressure level at operators ear | 89 dB(A) |
| Vibration | |
| Equivalent vibration level,(ahv, eq), front handle, collapsed | 6.3 m/s² |
| Equivalent vibration level,(ahv, eq), rear handle, collapsed | 5.3 m/s² |
| Equivalent vibration level,(ahv, eq), front handle, extended | 4.1 m/s² |
| Equivalent vibration level,(ahv, eq), rear handle, extended | 6.7 m/s² |
