Features
- X-Torq® engine cuts emission and fuel consumption
- Smart Start® for easy starting
- Adjustable cutter bar for greater versatility
- Extended reach with long cutter bar
- Auto return stop switch for easy starting
- Rear impact guard
- Intuitive controls
- Easy to service and maintain starter
- Cutter bar can be set in transport mode
- Air purge for easier cold starting
 |
Adjustable cutting bar
Adjustable cutting bar for greater versatility and less tiring work.
|
 |
Smart Start®
The engine and starter have been designed so the machine |
 |
X-Torq® engine
The X-Torq® engine design reduces harmful exhaust emissions by up to 75% and increases fuel efficiency by up to 20%. |
 |
Long cutter bar
Long cutter bar for extended reach |
Specifications
| Capacity | |
| Clutch engagement speed (±120) | 4700 rpm |
| Clutch engagement upper limit | 5500 rpm |
| Cutting speed | 4300 cut/min |
| Idling speed | 3000 rpm |
| Idling upper limit | 4000 rpm |
| Knife adjustment range, up/down Down | 90° |
| Knife adjustment range, up/down Up | 45° |
| Maximum power speed | 8500 rpm |
| Power output | 1kW |
| Racing speed lower limit | 10000 rpm |
| Teeth opening | 30 mm |
| Torque, max. | 1.2 Nm |
| Torque, max. at rpm | 6000 rpm |
| Dimensions | |
| Article gross weight | 7810 g |
| Article net weight | 7000 g |
| Knife Length | 60 cm |
| Weight | 6.3 kg |
| Engine | |
| Cylinder bore | 34 mm |
| Cylinder displacement | 25.4 см³ |
| Cylinder stroke | 28 mm |
| Engine Family CARB | HQZS.0254HD |
| Engine Family EPA | HQZS.0254HD |
| Gear ratio | 1 |
| Spark plug | Husqvarna HQT-2 |
| Lubricants | |
| Fuel consumption | 600 g/kWh |
| Fuel consumption | 0.6 g/kWh |
| Fuel tank volume | 0.5 l |
| Lubricant type | Husqvarna 2 stroke or equiv. at 50:1 |
| Power/fuel type | Gasoline |
| Emission Data Carb | |
| Engine Family EPA | HQZS.0254HD |
| Engine Family CARB | HQZS.0254HD |
| Exhaust emissions (CO average) | 254.31 g/kWh |
| Exhaust emissions (CO average) | 1120 g/kWh |
| Exhaust emissions (HC average) | 32.47 g/kWh |
| Exhaust emissions (NOx average) | 0.2 g/kWh |
| Emission Data EPA | |
| Exhaust emissions (CO average) | 254.31 g/kWh |
| Exhaust emissions (CO FEL) | 536 g/kWh |
| Exhaust emissions (CO average) | 1120 g/kWh |
| Exhaust emissions (HC average) | 32.47 g/kWh |
| Exhaust emissions (NOx average) | 0.2 g/kWh |
| Emission Data EU | |
| Exhaust emissions (CO average) | 418 g/kWh |
| Exhaust emissions (CO FEL) | 1141 g/kWh |
| Exhaust emissions (CO average) | 1141 g/kWh |
| Exhaust emissions (HC average) | 29.55 g/kWh |
| Exhaust emissions (NOx average) | 0.31 g/kWh |
| Sound and Noise | |
| Sound power level, guaranteed (LWA) | 107 db(A) |
| Sound power level, measured | 106 db(A) |
| Sound pressure level at operators ear | 95 db(A) |
| Vibrations | |
| Daily Vibration (Aeqv) | 4.6 m/s² |
| Daily Vibration Exposure (A8) | 3.0 m/s² |
| Daily Vibration Time (Time factor) | 3.5 h |
| Equivalent vibration level (ahv, eq) front handle | 4.6 m/s² |
| Equivalent vibration level (ahv, eq) rear handle | 3.9 m/s² |
