Features
- Deep cutting
- Optional 5th wheel to ease maneuverability
- Adjustable handles
- Optimised weight distribution
- Optimised display visibility
- Quick dis-engagement at blade slam
- Self-propelled
- Easy adjustment of tracking for straight cuts
- Low emissions
- Easy to operate
- Ergonomic
- Highly versatile 3-speed version
- Easy assembly of blade guard
- Intuitive and ergonomic control panel
- Powerful and productive
- Low maintenance
- Convenient transport between truck and work site
- Adjustable and telescopic pointer
- Automatic depth stop
 |
Optional 5th wheel to ease maneuverability
5th wheel option that helps raise and lower the rear of the saw, making it easier for the operator to pivot right or left. Particularly helpful when lining up a cut.
|
 |
Easy adjustment of tracking for straight cuts
Electric tracking system includes position indicator on the display, it can automatically return to neutral position and has the ability to memorise last used setting. |
 |
Adjustable and telescopic pointer
Provides good visibility when cutting and can be folded for transport. |
 |
Adjustable handles
Provides a closer and more comfortable position to the cutting side for easier alignment and straighter cuts. Handle can also be folded for transport. |
Specifications
| Engine | |
| Output power | 50.4 kW |
| Engine cooling | Liquid/Air |
| Fuel tank volume | 40 l |
| Number of strokes | 4-stroke engine |
| Cylinders | 4 |
| Power source | Diesel |
| Cutting Equipment | |
| Cutting depth (max) | 498 mm |
| Blade diameter (max) | 1,200 mm |
| Transmission | |
| Number of gearbox speeds | 3 |
| Transmission speed forward | 76 m/min |
| Transmission speed reverse | 0 m / min |
| Dimensions | |
| Product size length | 1,100 mm |
| Product size width | 1,700 mm |
| Product size height | 2,300 mm |
| Weight | Â 1,050 kg |
